Tor Memory Optimization: What Actually Works
Over the past four months, we conducted extensive memory experiments across 100+ relay-days on high-bandwidth Tor relays running Ubuntu 24.04 with Tor 0.4.8.x. Our goal: understand why Guard relays on Linux consistently see memory "stick" at 5–6 GB after ~48 hours—and how to fix it.
Key Findings
- The Culprit: Memory fragmentation in glibc's allocator, caused by high churn of Directory Cache objects
- False Hopes: Standard config tweaks like
MaxMemInQueuesdon't fix this. DisablingDirCacheworks but disqualifies you as a Guard - The Fix: Changing the memory allocator is the only viable solution
What We Tested
| Approach | Result | Viable? |
|---|---|---|
| mimalloc 2.1.2 | 1.16 GB (80% ↓) | ✅ Yes |
| jemalloc 5.3.0 | 1.59 GB (72% ↓) | ✅ Yes |
| tcmalloc 2.15 | 3.79 GB (33% ↓) | ⚠️ Partial |
| mimalloc 3.0.1 | 4.39 GB (23% ↓) | ⚠️ Partial |
| DirCache 0 | 0.29 GB (94% ↓) | ❌ Loses Guard |
| MaxMemInQueues | ~5 GB (no change) | ❌ No |
| MaxConsensusAgeForDiffs | ~5.7 GB (no change) | ❌ No |
| Periodic restarts | 5.0-5.3 GB (minimal) | ⚠️ Workaround only |
| glibc 2.39 (control) | 5.68 GB |
The Problem Visualized
The chart shows the stark difference: glibc 2.39 groups (D, E, Z) plateau at 5–6 GB while mimalloc 2.1.2 (B) and jemalloc 5.3.0 (A) stay under 2 GB. This isn't a gradual leak—it's a sudden expansion around Day 2 that never recovers under glibc.
Recommendation
For operators running Guard relays on Ubuntu 24.04, move away from the default allocator. Switching to mimalloc or jemalloc reduced our memory footprint by 70–80% without any loss in performance, stability, or Guard status.
# Ubuntu 24.04 - Quick deploy
sudo apt install libmimalloc2.0 # mimalloc 2.1.2
sudo systemctl edit tor@relay_name
# Add: Environment="LD_PRELOAD=/usr/lib/x86_64-linux-gnu/libmimalloc.so.2"With this single change, you can run more relays on the same hardware—capacity you can reinvest in the network.
📊 Raw data: View experiment data and relay configs on GitHub
